| Frame |
ALUXX SL-grade aluminum, 125mm travel FlexPoint suspension system, 148x12 rear axle, Universal Derrailleur hanger, 184x44 shock, 1.5~1.8" headset |
| Fork |
SR Suntour XCR 34 LO-R, 140mm travel, tapered steerer, Lockout, 110x15 thru-axle |
| Rear Shock |
SR Suntour Raidon R, 190x45mm, custom tuned |
| Rims |
Giant AM, Tubeless ready, 30mm inner width [F] 27.5" (S size), 29" (M/L/XL size) [R] Giant AM 27.5" , Tubeless ready, 30mm inner width |
| Hubs |
Giant eTracker Boost, [F] 110x15 [R] 148x12mm |
| Spokes |
Stainless Steel |
| Tires |
Maxxis Rekon 27.5x2.4"(S size), 29x2.4" (M/L/XL size), Foldable, TLR, EXO, 60TPI [F], Maxxis Rekon 27.5x2.4" Foldable, TLR, EXO, 60TPI [R] |
| Crankset |
FSA Comet E-Bike crank arm set FSA MegaTooth Direct-mount 1X steel 36T |
| Shifters |
Shimano Deore LinkGlide |
| Front Derailleur |
MRP HD2 co-moulded chain guide |
| Rear Derailleur |
Shimano Deore LinkGlide, 10-speed |
| Cassette/Freewheel |
Shimano LinkGlide, CS-LG400-10, 11-43T, 10-speed |
| Chain |
Shimano, LinkGlide, CN-LG500 |
| Brakes |
Tektro HD-M745 Orion, 4-piston, hydraulic disc, 203mm |
| Brake Levers |
Tektro HD-M745 Orion |
| Handlebars |
Giant Connect TR Riser 31.8x780mm |
| Tape/Grips |
Giant Connect ErgoMax lock-on |
| Stem |
Giant Contact |
| Seatpost |
Giant 30.9mm, 2-bolt Micro Adjustable, Forged aluminum |
| Saddle |
Giant Sport |
| Pedals |
Aluminum Platform |
| Accessories & Extras |
Giant Rekon E50 HL Axa BlueLine Steady E6 rear |
| Motor |
SyncDrive Sport, 75Nm, powered by Yamaha |
| Battery |
EnergyPak Smart 625, EnergyPak Plus 250Wh range extender compatible |
| Controller/Display |
RideControl Dash / RideControl Dash, full color LCD screen |
