Frame |
ALUXX SL-grade Aluminum, Advanced Forged Composite linkage, 140mm Maestro Suspension System, 'Boost' 148x12 UDH rear axle, Giant EnergyPak Plus Range Extender Compatible |
Fork |
Fox 36 Float Rhythm E-Tuned, 29er, 150mm travel, 44mm offset, Grip Damper, Sweep adjust, Boost 110x15QR |
Shock |
Fox Float DPS Performance, EVOL Large Volume sleeve, 3-position Lever, 185x52.5mm Trunnion mount, custom tuned |
Handlebar |
Giant Contact 35 Trail, 35x780mm |
Grips |
Giant New trail grip Half-waffle/single lock-on |
Stem |
Giant Contact SL 35 |
Seatpost |
Giant Contact Switch, dropper, 30,9mm (S:125/M:150/ L&XL:170) |
Saddle |
Giant Romero E |
Pedals |
Flatpedal |
Shifters |
Shimano SLX |
Front Der. |
MRP HD2 co-moulded chain guide |
Rear Der. |
Shimano SLX, 12-speed, Shadow+ |
Brakes |
Shimano Deore, BR-M6120, 4-piston, hydraulic disc, 203mm |
Brake Levers |
Shimano Deore, I-spec EV |
Cassette |
Shimano CS-M6100-12, 10-51T, 12-speed |
Chain |
KMC e.12 Turbo, EcoProteq, e-bike optimized |
Crankset |
Praxis Wavetm 36T Cold Forged 4130 premium steel Praxis e-Cadet+ custom forged crankarm set (Q-factor=168, S:160, M/L:165, XL:170) |
Bottom Bracket |
n/a |
Rims |
Giant AM 29", Tubeless ready, 30mm inner width |
Hubs |
Shimano MT410 Boost, Center-Lock, [F] 110x15 [R] 148x12mm Micro-Spline Drive Body Thru-axle |
Spokes |
Sapim E-Lite [R] Race [F], e-bike optimized |
Tires |
Maxxis Minion DHF 29x2.6" foldable, Tubeless, EXO+, 3C MaxxTerra [F] Maxxis Dissector 29x2.6" Foldable, Tubeless, EXO+, 3C MaxxTerra [R] |
Extras |
Tubeless kit (liquid, valves, levers, manual, tool) |
Motor |
SyncDrive Pro2, 85Nm, powered by Yamaha |
Display |
RideControl GO, frame integrated LED display ANT+ Wireless display compatible |
Battery |
EnergyPak Smart 800Wh EnergyPak Plus 250Wh range extender compatible |
Charger |
EnergyPak 6A smart charger |
