| Motor |
80Nm torque, 250W Mid Drive Motor, power by YAMAHA, SyncDrive Pro motor |
| Controller |
RideControl Dash, full color LCD screen, 5 power level plus auto mode |
| Display |
RideControl Dash, full color LCD screen |
| Battery |
500Wh capacity Integrated Panasonic cell, partner with Panasonic, EnergyPak Smart Compact 500Wh with optional Range Extender 500Wh compatiable |
| Range |
Primary battery: 35-60 mi (55-97 km); with optional auxiliary battery: 70-120 mi (110-194 km). Depending on riding mode and terrain |
| Charger |
Energypak 6A smart charger, fully re-charge in up to 4.1 hours |
| Frame |
ALUXX Aluminum, Low Step |
| Fork |
ALUXX Aluminium, Rigid Fork with Utility Feature |
| Rims |
Alloy, 35mm inner width, e-bike optimized |
| Hubs |
Shimano Nexus 5-Speed [R] |
| Spokes |
Stainless Steel, 13G[F] 13G[R] |
| Tires |
Maxxis Hook Worm, 24x2.5", Wire Bead, 60TPI |
| Bottom Bracket |
- |
| Crankset |
Forged Alloy minimal Q-factor, 46T |
| Shifters |
Shimano Nexus 5sp RevoShift |
| Rear Derailleur |
- |
| Cassette/Freewheel |
24T |
| Chain |
KMC Z1eHX NP/NP |
| Brakes |
Tektro HD-E737, 4-piston, hydraulic disc for Cargo, 203mm [F&R] |
| Brake Levers |
Tektro 2 Fingers |
| Handlebars |
Aluminium 20D Sweep Back, Rise 50 mm, Width: 720mm, TR49A-00S1 |
| Stem |
Giant Contact |
| Seatpost |
Suspension Dropper 30.9mm, Travel: 40mm, Height 70mm Adjustment |
| Saddle |
Momentum Saddle w/ Rear Handle |
| Pedals |
Anti-Slip |
| Extras |
Lockable storage console, alloy fenders, chainguard |
| Lighting |
Supernova E2 Mini ProAxa BlueLine Steady E6 rear |
| Carrier |
Alloy Front/ Rear Carrier |
| Cargo Load Limits |
Front cargo basket: max 33 lbs (15kg), rear rack: max 102 lbs (46kg) |
| Total Load Limit |
361 lbs (164kg) |
| Weight |
79lbs(36kg), including the main battery inside.(w/o kickstand and front basket) |
