| Frame |
Aluminum, Smooth Welding, 12x148mm Boost, Tapered HT, UDH Hanger |
| Fork |
X-fusion RC32 Air, 130mm, 15x110mm Boost |
| Rims |
WTB ST TCS 2.0, 27mm ID, 32H |
| Hubs |
Front: Formula Sealed Bearing 110x15 32H
Rear: Formula DC-3248,12x148mm Boost, HG, 32h, 6-bolt |
| Spokes |
Stainless Steel, 14g |
| Tires |
Front: Maxxis Forekaster, 29X2.4" (27.5X2.25" Size S), Wire
Rear: Maxxis Forekaster, 29X2.4" (27.5X2.25" Size S), Wire |
| Bottom Bracket |
Shimano Cartridge BB for 2 pc crank |
| Crankset |
Prowheel Alloy, 30T, 170mm (S-M), 175mm (L - XXL) |
| Shifters |
Shimano Deore SL-M6100-R, 12sp |
| Rear Derailleur |
Shimano Deore RD-M6100, 12sp, SGS |
| Cassette/Freewheel |
Shimano Deore CS-M6100, 10-51T, 12sp |
| Chain |
KMC 12spd |
| Brakes |
Tektro HD-M275, Resin pads |
| Rotors |
Tektro. 160mm, 6-bolt |
| Brake Levers |
Tektro HD-M275 |
| Handlebars |
Norco Aluminum, 780mm, 30mm Rise |
| Tape/Grips |
DDK lock-On, 139mm length |
| Stem |
Alloy 40mm Length, 31.8mm Clamp |
| Headset |
Sealed Cartridge Bearings, Tapered 1-1/8" - 1.5" ( IS42/28.6 | IS52/40 ) |
| Seatpost |
X-Fusion Manic LC, 31.6mm, 130mm (S), 150mm (M), 170mm (L/XL/XXL) |
| Saddle |
Norco XC, Steel Rail |
