NORCO SIGHT A2 MX | BLACK
NORCO SIGHT A2 MX | BLACK
NORCO SIGHT A2 MX | BLACK
NORCO SIGHT A2 MX | BLACK
NORCO

SIGHT A2 MX | BLACK

•••••
Size :
+-
C$5,048.99
Add to cart
1 in stock
  • Details

    • Whether you're carving down a steep loam line, dropping in for an enduro stage, or heading into the backcountry for an all-day epic, this bike performs. With increased rearward axle path, idler, and the innovative VPSHP suspension layout, this new design gives the Sight next level confidence and capability, up or down the mountain. With 160/150mm of travel, the 2024 Sight takes the best of the Range Platform and has tighten it up into a light, pedal friendly, maneuverable, high-pivot package.

    Available with a 27.5" rear wheel (MX), as well as 29" in some markets. Swapping the linkarm and lower shock mount with the "Missing Link Kit" converts between 27.5" and 29" to let you pick the wheelsize that suits you best while maintaining geometry and kinematics to ensure consistent fit and bike setup.

    - 29" with the option to change to 29"/27.5" with no compromise geometry and kinematics.
    - Fox Float suspension.
    - Co-molded frame protection.
    - Weight (S3): 17.6 kg / 38.8 lbs
    - Ride AlignedTM – Perfect fit, dialed handling and personalized setup in minutes.
    - New No Other Way Limited Lifetime Warranty

    Specs

    Pedals Sold Seperately
    Fork Fox FLOAT 36 Rhythm, Sweep Adjust, 160mm, 44mm Offset
    Hubs Front: Shimano SLX 15x110mm Boost, Center Lock Rear: Shimano SLX FH-M7110, Micro Spline, Center Lock
    Rims Stan's Flow D, Black 32H, 29"/27.5"
    Stem Alloy, 40mm Length, 35mm Clamp
    Chain Shimano Deore CN-M6100
    Frame Sight Aluminum, VPSHP, 150mm Travel, UDH Compatible
    Tires Front: Maxxis Minion DHF 2.5', 3C, MaxxTerra / EXO+ / TR, Folding Rear: Maxxis Minion DHR II 2.4" WT, 3C, MaxxTerra / EXO+ / TR, Folding
    Brakes Shimano Deore MT520 4 Piston, Metallic Pads
    Rotors Front: Shimano RT-64, 200mm Rear: Shimano RT-64, 180mm
    Saddle SDG Bel Air V3
    Spokes Black Stainless
    Headset FSA #57 E Sealed Bearing
    Crankset Shimano SLX HollowTech 2, FC-M7100, 34T, 32T on Size 1, 170mm
    Seatpost TranzX YS105 Dropper, 34.9mm, 150mm (1), 170mm (2), 200 (3, 4), 230mm (5)
    Shifters Shimano SLX SL-M7100-R
    Handlebars 6061 Alloy, 800mm, 25mm Rise
    Rear Shock Fox FLOAT X Performance, LSC LSR, 205x60mm Trunnion
    Tape/Grips SDG THRICE
    Brake Levers Shimano Deore MT-520
    Bottom Bracket Shimano Sealed Bearing BSA Threaded
    Rear Derailleur Shimano SLX RD-M7100
    Cassette/Freewheel Shimano SLX CS-M7100-12, 10-51T, 12 Speed

    * Subject to change without notice.

    GEOMETRY

    Sizes:
    Frame Size 1 2 3 4 5
    Wheel Size 29"/27.5" 29"/27.5" 29"/27.5" 29"/27.5" 29"/27.5"
    Travel (mm front/mm rear) 160/150 160/150 160/150 160/150 160/150
    Reach (mm) 422.5 447.5 472.5 497.5 522.5
    Stack (mm) 618 627 636 645 654
    Head Tube Angle 64° 64° 64° 64° 64°
    Fork Offset (mm) 44 44 44 44 44
    Seat Tube Length (mm) 350 370 385 430 445
    Effective Seat Tube Angle 77° 77.25° 77.5° 77.75° 78°
    Rear Centre Length (mm) 420 424 428 432 436
    Bottom Bracket Drop (mm) 25/25 25/25 25/25 25/25 25/25
    Bottom Bracket Height (mm) 353 353 353 353 353
    Horizontal Top Tube (mm) 565 589 613 637 661
    Wheelbase (mm) 1181 1214 1247 1281 1314
    Standover (mm) 666 680 689 710 720
    Head Tube Length (mm) 105 115 125 135 145
    Trail (mm) 135 135 135 135 135
    Recommended Seatpost Drop (mm) 150 170 200 200 230
    Maximum Post Insertion (mm) 250 270 300 300 330
    Stem Length (mm) 40 40 40 40 40
    Crank Length (mm) 170 170 170 170 170
    Tire Size 2.35" – 2.6" 2.35" – 2.6" 2.35" – 2.6" 2.35" – 2.6" 2.35" – 2.6"
    Water Bottle Compatible 1 x 750 mL 1 x 750 mL 1 x 750 mL 1 x 750 mL 1 x 750 mL

    SIZING

    Sizes:
    Frame Size Rider Height (cm) Rider Height (in)
    1 150 - 165 5'0" - 5'5"
    2 162 - 172 5'4" - 5'8"
    3 170 - 180 5'7" - 5'11"
    4 177 - 187 5'10" - 6'2"
    5 185 - 200 6'1" - 6'6"
