The Bosch Performance Line CX motor gets you to the drop-in of the deepest, wildest trails. Built tough for the biggest terrain, the Bullit is the closest it gets to owning both a downhill bike and a chairlift
Specs
| Frame |
Carbon C |
| Fork |
FOX 38 Float Performance, Grip, 170mm |
| Rear Shock |
FOX Float X Performance, 205x65 |
| Rims |
Reserve 30|HD AL 6069 |
| Hubs |
Front: E13 SL, 15x110, 6-Bolt, 32h
Rear: E13 SL E-Spec, 12x148, XD, 6-Bolt, 32h |
| Tires |
Front: Maxxis Assegai 29"x2.5", 3C, MaxxGrip, Double Down
Rear: Maxxis Minion DHRII 27.5x2.5, 3C MaxxTerra, DoubleDown |
| Bottom Bracket |
N/A |
| Crankset |
E13 Helix eSpec, 155mm |
| Shifters |
SRAM 90 Eagle T-Type, Single Click, 12spd |
| Rear Derailleur |
SRAM 90 Eagle T-Type, 12spd |
| Cassette/Freewheel |
SRAM XS 1275 Eagle T-Type, 10-52t |
| Chain |
SRAM GX Eagle T-Type, Flattop, 12spd |
| Brakes |
SRAM Maven Bronze |
| Rotors |
Front: SRAM HS2 200mm
Rear: SRAM HS2 200mm |
| Handlebars |
OneUp Aluminum Bar, 35mm Rise, 800mm |
| Tape/Grips |
Santa Cruz Bicycles House Grips |
| Stem |
OneUp Stem, 42mm |
| Headset |
FSA IS-2/47/42 ACB |
| Seatpost |
OneUp Dropper Post, 31.6 |
| Saddle |
SDG Bel-Air V3 Max Lux-Alloy |
| Motor |
Bosch Performance Line CX |
| Battery |
Bosch PowerTube Battery 600Wh |
* Subject to change without notice.
GEOMETRY
All units are in millimeters or degrees.
| |
S |
M |
L |
XL |
XXL |
| Reach (Hi/Lo) |
435/432 |
460/457 |
480/477 |
500/497 |
525/522 |
| Stack (Hi/Lo) |
622/625 |
631/635 |
640/643 |
654/656 |
670/674 |
| Head Tube Angle (Hi/Lo) |
63.6/63.3 |
63.6/63.3 |
63.6/63.3 |
63.6/63.3 |
63.6/63.3 |
| Head Tube Length |
100 |
110 |
120 |
135 |
155 |
| Rear Center |
440 |
443 |
446 |
449 |
452 |
| Front Center |
780 |
809 |
834 |
860 |
894 |
| BB Height (Hi/Lo) |
346/342 |
346/342 |
346/342 |
346/342 |
346/342 |
| BB Drop Front (Hi/Lo) |
27/31 |
27/31 |
27/31 |
27/31 |
27/31 |
| BB Drop Rear (Hi/Lo) |
9/13 |
9/13 |
9/13 |
9/13 |
9/13 |
| Wheelbase |
1220 |
1252 |
1280 |
1309 |
1346 |
| Top Tube Length |
571 |
596 |
617 |
640 |
670 |
| Seat Tube Length |
380 |
400 |
420 |
460 |
500 |
| Seat Tube Angle (Hi/Lo) |
78.6/78.3 |
78.7/78.4 |
78.7/78.4 |
78.7/78.4 |
78.6/78.3 |
| Standover Height (Hi/Lo) |
745/740 |
739/735 |
738/733 |
738/733 |
735/730 |
SIZING
Small: 5'1"-5'5" Reach: 435mm
Medium: 5'5"-5'9" Reach: 460mm
Large: 5'9"-6'1" Reach: 480mm
X-Large: 6'1"-6'4" Reach: 500mm
XX-Large: 6'4"-6'7" Reach: 525m
